Does anyone have the Nash Les Paul wiring schematic?

[Mr. Papa]

I thought I had one saved somewhere but I can't find it now. They wired it to split the humbuckers to single coil when the tone knob was on ten, it worked really well. TIA!



[jb_abides]

Found on the interwebz ...



Other candidates:



[RJLII]

Here's another approach that Gibson used on the GK-55. Two tones, master volume, and master variable coil split. A good friend has a GK-55 and this approach works well. The Bill Nash approach sort of mimics what Peavey did on the T-60 model. I had one of those and felt being able to split the pickups independently was a superior approach.



[Mr. Papa]

Hey, thanks to you both! That's what I am looking for -- I promise I did try an Internet search before asking. I must be getting old.
